Magneto

Home › Forum › Ask A Member › Magneto

Viewing 9 posts - 1 through 9 (of 9 total)
  • Author
    Posts
  • July 3, 2018 at 2:53 pm #10454
    cingalls
    Participant

      US Member

      Is there any place in the Los Angeles area to have the magnets on a magneto flywheel re-charged?

      July 3, 2018 at 3:52 pm #78958
      frankr
      Participant

        US MEMBER PAY BY CHECK

        Are you sure they need to be recharged? How old is it?

        July 3, 2018 at 5:20 pm #78961
        Tubs
        Participant

          What motor are you working on.
          If your motor was built after WW-II it will
          have permanent magnets. Trying to recharge
          them will only damage them and there is no
          repair. If you magnets are strong enough
          to make a spark increasing the magnetism
          wonk make a better spark. That is why you
          can take a coil out of one of these and it
          will make a really good spark in one of these
          with its tinny little magnets.

          https://www.youtube.com/watch?v=72KgjVyTPAg
          https://www.youtube.com/watch?v=71W9cPMV09A

          A "Boathouse Repair" is one thats done without having tools or the skills to do it properly.

          July 3, 2018 at 9:39 pm #78971
          cingalls
          Participant

            US Member

            It is makeing spark. This is a 1930’s PR racing engine. Runs on Methanol. 30 cubic inch. I was told if the magnets are fully charged it will help it start easier. Although, it does start quite easily so I may be wasting my time and maybe creating more trouble than what I think I’m gaining. Thanks for your input.

            July 3, 2018 at 11:33 pm #78982
            Tubs
            Participant

              increasing the magnetism doesn’t increase the strength of the spark.
              How fast the magnets pass over the coil does. The faster a magneto
              spins the stronger the voltage. Its why they still use magnetos in these
              things.

              A "Boathouse Repair" is one thats done without having tools or the skills to do it properly.

              July 4, 2018 at 3:25 pm #79024
              cingalls
              Participant

                US Member

                Thanks for your input, I think I’ll leave it alone. I’m heading to the Nationals in DePue Il and was looking for for any advantage.

                July 4, 2018 at 6:59 pm #79032
                Tubs
                Participant

                  I think most everyone here would like to see that thing run.
                  How about some pictures and maybe some video when you get back?

                  A "Boathouse Repair" is one thats done without having tools or the skills to do it properly.

                  July 4, 2018 at 11:55 pm #79044
                  fisherman6
                  Participant

                    US Member

                    Yes! Very much! Video of it running would be great! Pics better than nothing.
                    -Ben

                    OldJohnnyRude on YouTube

                    July 5, 2018 at 10:56 am #79057
                    garry-in-michigan
                    Participant

                      Lifetime Member

                      The PR was built with soft iron magnets in the flywheel. A "keeper" should be placed across the magnetic poles whenever the flywheel is off the motor. Other wise the magnet may weaken if the flywheel is dropped. . . 😉
