Topic: 1942 4366 Coil & Ignition parts – Where can I find these?

This topic has 6 replies, 5 voices, and was last updated 9 years, 10 months ago by mikele86.

Viewing 7 posts - 1 through 7 (of 7 total)

Author

Posts
December 21, 2015 at 3:42 pm #3231
mikele86
Participant
Hi all, I noticed the ignition system on this motor looks a little different then the last few I’ve worked with.. for one the points are completely different. Where can I find these parts to get this back up and firing spark? Thanks!
December 22, 2015 at 2:55 am #29005
wedgie
Participant
You can probably get away with cleaning the points. Just make sure you don’t lose the tiny washers !
December 22, 2015 at 3:09 pm #29020
mikele86
Participant
quote Wedgie:

You can probably get away with cleaning the points. Just make sure you don’t lose the tiny washers !

Thanks! The coil looks intact, if not functional are these readily available?
December 22, 2015 at 3:28 pm #29023
kevinf
Participant
Have you checked the coil with an ohm meter? That will tell you if you need to go looking for a coil. The points likely just need a cleaning as Wedgie said. I expect that you’ll be looking for NOS or used parts if anything needs replacing but the good news is that you’re in the right place to find parts if you need them.

Kev
December 22, 2015 at 3:56 pm #29028
jeff-register
Participant
US Member
Mike,
Use your ohmeter & test both windings in the coil. I take my points off the plate & wire wheel the contact point areas, then file just enough to get 100% good contact using the meter again. You really need a Mercotronic to test the cap. If it is good you will get a spark but if it has failed look for a weak spark.
December 22, 2015 at 6:36 pm #29038
cajuncook1
Participant
mikele86, I’m going to supply a you tube video link that Doug Penn posted to help test your coil with an ohm analog meter. Doug Penn is also a guy who may have good used coil, points, and condenser for you motor if you should need.

https://www.youtube.com/watch?v=KT8rk5QWgS0

Here is link to his website as well.

http://penn.itgo.com/
December 22, 2015 at 7:56 pm #29043
mikele86
Participant
quote cajuncook1:

mikele86, I’m going to supply a you tube video link that Doug Penn posted to help test your coil with an ohm analog meter. Doug Penn is also a guy who may have good used coil, points, and condenser for you motor if you should need.

https://www.youtube.com/watch?v=KT8rk5QWgS0

Here is link to his website as well.

http://penn.itgo.com/

Thanks for the feedback guys!

I actually met doug a few weeks back when buying parts from him. Great guy!! and his collection was unreal! I will reach out to him again when he is back from FL
