  • September 5, 2019 at 2:55 pm #182695
    rapier
    Participant

      Struggling to understand how the tiller and throttle cable to carb synchronisation & carb openings works on my ’46 Speeditwin. It was a project with a British Seagull / Villiers style throttle system originally, so I have no reference on how to do the setup. Everything is installed as per the grip schematic and the two pics you see (not my motor), but I’ve no manual as to how the throttle handle needs to be in relation to carb throttle openings / closing.

      September 5, 2019 at 11:09 pm #182724
      garry-in-michigan
      Participant

        Lifetime Member

        You’re worrying too much. Clean up the tiller and assemble it with a little lithium grease. (Lubraplate typeA – AKA LubraMatic) It only goes together one way. The adjustments are made at the carburetor. With the grip in the start position(straight up, midway between fast and slow) the throttle valve in the carburetor likewise should be adjusted to be half way open. Here is the starting instructions from the service manual . . .


        September 6, 2019 at 9:13 am #182745
        wbeaton
        Participant

          We ran a 1950 Speeditwin last night. The twist throttle doesn’t do much. The timing advance does most of it. Fun motor.

          86863622-4064-4792-AE74-65CB2E2F3BF5

          Wayne
          Upper Canada Chapter

          uccaomci.com

          September 6, 2019 at 10:33 am #182755
          rapier
          Participant
            garry-in-michigan wrote:

            You’re worrying too much. Clean up the tiller and assemble it with a little lithium grease. (Lubraplate typeA – AKA LubraMatic) It only goes together one way. The adjustments are made at the carburetor. With the grip in the start position(straight up, midway between fast and slow) the throttle valve in the carburetor likewise should be adjusted to be half way open. Here is the starting instructions from the service manual . .

            Garry, thanks, much appreciated. Here’s the motor, I wanted to use it, so kept parts of it as found.

            I normally use lubriplate 105 in the LUs. Instead this green grease is in there, it doesn’t smell of grease or anything..can anyone identify what it might be?

            September 6, 2019 at 10:35 am #182758
            rapier
            Participant

              Looks great, I like the woody too.

              September 6, 2019 at 10:55 am #182760
              kirkp
              Participant

                Maybe John Deere cornhead grease

                September 6, 2019 at 11:35 am #182769
                wbeaton
                Participant

                  Could be TSC Cottonpicker grease 00. If it’s thin enough I’d use it.

                  Wayne
                  Upper Canada Chapter

                  uccaomci.com
