1954 25 HP Evinrude head Torque value

Home Forum Ask A Member 1954 25 HP Evinrude head Torque value

Viewing 4 posts - 1 through 4 (of 4 total)

  • Evinrude 25


    Replies: 135
    Topics: 29
    #209219

    Hello,
    Currently I am working on 1954 25 Hp Evinrude. Could I reused the head gasket? The cylinder compression is 90/88 psi. Is it acceptable for this 46 year old motor?
    What is the head torque valve?


    Steve Martin

    US Member - 1 Year (includes $3 online payment fee)
    Replies: 156
    Topics: 28
    #209228

    1565005771478


    Steve Martin

    US Member - 1 Year (includes $3 online payment fee)
    Replies: 156
    Topics: 28
    #209232

    I believe your specs are the same as the early Johnson RD.


    labrador-guy

    US Member - 2 Years
    Replies: 1063
    Topics: 72
    #209235

    Erudnaquarter your math is a little off, that old kicker is 66 years old! No worries I have the same problem now and then. As for reusing the head gasket. Ask your self “how does it Look”. I have reused them occasionally. New gasket is the best, but that old motor might not have the original gasket. Use some sealer if you reuse the old one and putting a little sealer on the bolt treads won’t hurt either. Your compression is reasonable. Torque value you will have to look up.

    dale

    • This reply was modified 3 years, 8 months ago by labrador-guy.
